Welded Mesh
PVC welded mesh is a mesh product made with polyvinyl chloride as the main raw material. It is produced by mixing and extruding to form plastic wires of uniform specifications, then fixing the crisscross PVC wires at their intersections through hot-melt welding, where the intersections are fused together. It can be customized in terms of mesh size, wire diameter, and mesh dimensions according to requirements. Available in various colors (white, green, blue, black, etc.), it contains no metal components and is lightweight overall.
Features
01
Strong chemical stability
Resistant to corrosion by acids, alkalis, and organic solvents, and does not react with water, oils, or greases.
02
Excellent insulation performance
Completely non-conductive and non-thermal conductive, capable of isolating the transmission of electric current and heat.
03
Impact resistance
Flexible and elastic in texture, not prone to embrittlement or fracture when impacted by external forces, with no risk of shattering.
04
Smooth and easy-to-clean surface
No pores, does not absorb stains, can be directly rinsed with water, and is not easy to breed mold.
05
Long-lasting color
Made with color masterbatch in one-piece molding, the color penetrates into the material, and it is not easy to fade even when exposed to sunlight for a long time.
PRODUCT ADVANTAGES
Low cost and easy maintenance
Raw material prices are lower than those of metal, and later maintenance costs are almost zero.
Lightweight and efficient installation
Weighing only 1/5 of the same-specification metal mesh, it can be cut and spliced by hand without professional tools.
Environmentally friendly
Can be recycled and reused after disposal, meeting environmental protection requirements, and some products are biodegradable.
High safety
No sharp edges, so it will not cause scratches during use.
Flexible scenario adaptability
Can function stably in various environments and is not affected by climate.
Specification
| Opening（inch） | Opening（mm） | Diameter (BWG) |
| 1/2''×1/2'' | 12.7×12.7 | 16,17,18,19,20,21 |
| 3/4''×3/4'' | 19×19 | 16,17,18,19,20,21 |
| 1''×1'' | 25.4×25.4 | 15,16,17,18,19,20 |
Applications
Home and indoor scenarios: Safety fences for children's play areas, pet isolation nets for balconies, wardrobe partition nets, ceiling decorative nets, and base nets for bathroom anti-slip mats.
Electrical and industrial auxiliary: Insulation isolation nets around distribution boxes, anti-static isolation nets in electronic workshops, and temporary safety enclosures during equipment maintenance.
Agriculture and horticulture: Climbing nets for crops in greenhouses, isolation nets for rare plants in botanical gardens, protective nets for home flower pots, and temporary enclosures for aquaculture.
Outdoor and municipal use: Boundary nets for park lawns, temporary fences for festivals and celebrations, warning nets for road construction, and protective nets for landscape pools.
Packaging and transportation: Packaging net covers for light goods and classification isolation nets for scattered items in warehousing.
FAQ
1. Can your PVC welded mesh be used outdoors?
We use high-quality PVC with added anti-UV additives, ensuring a long service life outdoors.
2. How is the impact resistance of your PVC welded mesh? Can it withstand external impacts?
Our PVC welded mesh has certain toughness and can withstand impacts from poultry and the like.
3. Are the welding points of your PVC welded mesh easy to fall off?
We use high-frequency welding technology, and the welding point pull force exceeds industry standards.
4. How recyclable is your PVC welded mesh? Is it an environmentally friendly material?
Our PVC welded mesh is a recyclable plastic and meets environmental protection requirements.
5. Can you ensure that PVC welded mesh won’t be crushed or deformed during transportation for bulk purchases?
Our PVC welded mesh is packaged in rolls with rigid cartons or wooden boxes to ensure no deformation during transportation.
