Stainless Steel Welded Mesh

Stainless steel welded mesh is made of stainless steel wires, which are welded and fixed at the intersection points by automated resistance welding equipment. In the production, the steel wires are straightened, cut, and then precisely arranged according to the preset mesh holes, and the contact points are fused and combined through the high temperature of the electric current to form a whole mesh without looseness and burr, taking into account the rigidity and structural stability. Common materials include 304, 304L, 316, 316L, 310, 310S, 314, 321, and Hanrun can customize mesh materials and sizes according to requirements.

Inquire Now

Features

Corrosion and oxidation resistance

Relying on the properties of stainless steel itself, it can maintain stable performance in acid - alkali environments, high - temperature and humid conditions.

High - temperature resistance

Stainless steel can withstand relatively high temperatures, and its structure and performance are not easily changed in high - temperature environments.

Strong and uniform structure

The welding points have high strength, and the overall rigidity of the mesh sheet is strong, with no risk of local looseness or deformation.

High precision controllability

The mesh size is uniform and neatly arranged, and the error can be controlled within a very small range.

Excellent hygienic performance

The surface is smooth and easy to clean, not easy to breed bacteria, and no heavy metals are precipitated, meeting the hygienic standards of industries such as food and medicine.

PRODUCT ADVANTAGES

Ultra - long service life

In harsh environments, the service life can reach more than 10 years, far exceeding that of ordinary metal meshes, greatly reducing the replacement frequency and maintenance cost.

Wide environmental adaptability

It can work stably from sub - zero low temperatures to high temperatures, from the high - salt - fog environment by the sea to the corrosive atmosphere in chemical workshops.

High safety factor

There are no sharp protrusions at the welding points, not easy to cause scratches during use, and it has strong impact resistance, which can effectively resist external impacts.

Convenient secondary processing

It can be cut, bent, punched, etc. according to actual needs, adapting to the installation requirements of different equipment or scenarios.

Specification

Opening（inch）	Opening（mm）	Diameter<BWG>
1/4''×1/4''	6.4×6.4	22,23,24
3/8''×3/8''	10.6×10.6	19,20,21,22
1/2''×1/2''	12.7×12.7	16,17,18,19,20,21,22,23
5/8''×5/8''	16×16	18,19,20,21
3/4''×3/4''	19.1×19.1	16,17,18,19,20,21
1''×1/2''	25.4×12.7	16,17,18,19,20,21
1 - 1/2''×1 - 1/2''	38×38	14,15,16,17,18,19
1''×2''	25.4×50.8	14,15,16
2''×2''	50.8×50.8	12,13,14,15,16

Applications

Food and pharmaceutical industries: Used as isolation nets in food processing lines, medicinal material screening nets, and protective fences in clean workshops.

Chemical and environmental protection fields: Used as filter screens for acid - alkali solutions, interception nets for sewage treatment equipment, and protective nets for corrosive liquid transmission pipelines.

Construction and decoration projects: Used as curtain wall decorative nets, protective nets for stair handrails, and safety isolation nets for equipment platforms.

Marine and outdoor scenario: Used as protective nets for breakwaters in coastal areas, safety nets on ship decks, and high - end outdoor fences (such as in villa areas, golf courses).

FAQ

1. In which industries is stainless steel welded mesh applicable?
It is widely used in protective barriers, construction support, mechanical protection, elevator shafts, breeding, screening, etc.

2. What is the difference between your welded mesh and woven mesh?
Welded mesh is formed by spot-welding horizontal and vertical wires, featuring a sturdy structure and uniform mesh. It has higher strength compared to woven mesh. Made of 304 or 316 stainless steel, it offers long-term corrosion resistance and rust resistance, suitable for outdoor and humid environments.

3. Can your stainless steel welded mesh be customized in terms of mesh size and wire diameter?
Of course. Common mesh sizes include 1/4", 1/2", 1", 2", etc. Wire diameter and dimensions can also be customized as needed.

4. Do you provide stainless steel welded mesh in sheet or roll form?
Both are available. Sheet mesh is suitable for structural use, while roll mesh is ideal for continuous installation. Custom sizes are supported.

5. How strong are the welds of your stainless steel welded mesh?
We use automatic resistance welding machines or precision spot welders, ensuring strong welds that won’t break.
